From the top toolbar, choose Extensions -> GCodeTools -> Orientation Points.Clone this layer to a new layer above this one and hide and lock all sublayers.

At this stage, your artwork is complete.

If you have overlapping nodes (e.g., two lines coming to a point), use the ‘join nodes’ tool to combine them. Having a huge number of nodes will lead to having many many tiny steps that the printer will execute, increasing pritn time and reducing stability.

Before you proceed, go to node view (n) and try to simplify the nodes as much as you can while maintaining pattern fidelity.
